A five-star hotel28 floors + 2 underground levels
RS3100 same-frequency repeater + Pro+ passives + CV110 fiber BDA; four independent talk groups, zero underground dead zones
JT-2026 / 20+ YEARSNarrowband baseline · Broadband value-add · Unified dispatchKey industries · Mine / Tunnel / Site / Energy & Chemical
Hotel / hospital / campus radios always cross-talk?
No signal in garage or tunnel?
KINGTONE Solutions fixes it in one go
Narrowband radio + signal coverage + passive components + NMS & dispatch, covering hotel / hospital / campus / transport hub / smart manufacturing / energy & chemical / emergency command across 12 major scenarios; 20+ years of R&D, 7000+ projects delivered.
- SRRC Model Approval
- 13 Utility-Model Patents
- 11 Software Copyrights
- ISO Triple-System Certifications
A
B
C
D
COVERAGE SIMULATION4 SECTOR / 11 SCENE- 20+
- Years of R&D
- 13items
- Patents
- 11items
- Software copyrights
- 7000+
- Projects delivered
01 / SCENARIO ENTRY
12 industry scenarios — match your pain point directly
Each scenario is its own solution page: problem breakdown → device config → project parameters → case data
02 / TECH ARCHITECTURE
Broadband–Narrowband Five-Layer Architecture
From edge terminals to unified dispatch: one architecture covering voice, coverage, broadband, and O&M — avoiding the accountability vacuum of multi-vendor assembly
L1Terminal AccessTERMINAL
DMR digital handheld / mobileBroadband–narrowband terminalVideo & positioning terminal
L2Coverage & DistributionCOVERAGE
Fiber BDA CV110 / 120Wireless broadband BDA CV210ICS interference cancellation CV310Pro+ manageable passives
L3Relay & SwitchingRELAY
RS3100 same-frequency repeaterRS3500 digital repeaterPrivate-network base station B3xx / B4xx
L4Core BearerCORE
EPC / 5GC coreIMS switching VoLTE↔SIP1.4G / 1.8G private bands
L5Application & O&MAPPLICATION
S200 device NMSS300 multimedia dispatchS400 maintenance subscription
DESIGN PRINCIPLE
Baseline first, then value-add
Solidify narrowband coverage first, then layer broadband services — avoiding one-time over-investment and a system that cannot pass acceptance.
- Narrowband baseline
Voice available under any condition, no public-network dependency
- Broadband value-add
LTE/5G industry private network carries video backhaul and personnel positioning
- Unified dispatch
Voice + video + GIS fused onto one map
LINK BUDGET / TYPICAL LINK DIAGRAMIllustrative structure; actual configuration per on-site survey and contract technical agreement
- RELAY OUTPUT
- 25W
- FORWARD DELAY
- 90ms
- ICS CANCELLATION
- ≥30dB
- COVERAGE
- Continuouszero dead zone
RS3000 split-frequency repeater rated output
RS3100 same-frequency repeater forwarding latency
CV310 same-frequency interference cancellation
Fiber or wireless distribution coverage
03 / TECH & SERVICE CAPABILITY
Six core capabilities, each verifiable
No adjective piling — behind every capability hangs a patent number, software-copyright registration, or model approval; verifiable and accountable
RF ENGINEERING
Microwave & RF Engineering
From component to system — we design every stage of the RF chain ourselves
- Dual-band / multi-band BDA platform: one RF front end adapts to multiple band combinations, cutting on-site retrofit cost
- Self-designed cross-band duplexer — isolation and rejection specs enforced to engineering red lines, not pieced together from bought modules
- Strict non-interchangeable uplink/downlink signal extraction (uplink RF420 / downlink RF430) — eliminates reverse crosstalk and receiver damage
- High-power linear amplification + ALC automatic level control — no drift under long full-power runs; low-noise receive chain designed to noise-figure targets
- Structural reliability backed by patents: moisture/heat dissipation, cable management, anti-wind antenna mounting, anti-detachment data interfaces
EVIDENCE
13 utility-model patents (2 RF core + 5 structural)Cross-band duplexer ZL 2019 2 0544785.7SRRC radio-transmission equipment model approval
RELATED PRODUCT LINEKT-CV CoverageKT-RF PassivesKT-RS Repeaters
Technical detail04 / SERVICE & DELIVERY
One system, two markets, two service radii
Domestic: localized delivery & spare-parts support; overseas: own-brand export & English technical support — not one playbook for both
Domestic MarketCHINA MARKET
Localized delivery across 12 industry scenarios
- 7000+ projectsHotels, hospitals, campuses, transport hubs, smart manufacturing, energy & chemical, tunnels, emergency — all scenarios landed
- Survey-firstMeasure before design; provide constructable plan by building structure and interference environment
- Local spare parts & responseDevices and passives locally supplied; faults quickly recovered by swap
- Maintenance subscription optionalS200 management + remote inspection — hand the system to a party that owns it long-term
Overseas MarketGLOBAL MARKET
Own-brand export with English technical support
- KINGTONE brand exportOverseas operated under KINGTONE, running dual-track with domestic JIMTOM
- International trademarkMadrid system extends to EU, India, Philippines, Vietnam; US trademark application in progress
- English technical docsSpecs, drawings and acceptance standards delivered in English; engineers can deploy directly
- Remote supportRemote commissioning and technical response, with spare-parts strategy and cross-time-zone communication
DELIVERY PROCESSA six-step closed loop from survey to O&M; every step has a deliverable
- 01SurveySURVEY
Building structure, existing network, interference-source check — output survey record
- 02DesignDESIGN
Link budget, coverage simulation, equipment selection and topology diagram
- 03SuperviseSUPERVISE
Cable routing, device installation, on-site process-standard control
- 04CommissionCOMMISSION
Power and gain adjustment, isolation and interference retest
- 05AcceptACCEPT
Field strength, call quality, latency and other metrics archived item by item
- 06OperateOPERATE
NMS management, remote inspection, fault response and spare-parts support
05 / SOLUTION PACKAGES
Not sure how to choose? Match a package by scenario
Equipment + passives + software + maintenance delivered at once; quote and timeline clearly traceable
SOL200Hotel · Hospital · Commercial building
Hotel / Building Coverage Package
- CONFIGURATION
- RS3100 same-frequency repeater + Pro-grade passives + coverage antennas
- BEST FOR
- Single building, up to 50,000 m²; fixes cross-talk and underground dead zones
SOL300Industrial park · Campus · Property management
Campus Security & Dispatch Package
- CONFIGURATION
- RS3500 digital repeater + combining/splitting system + S300 dispatch console
- BEST FOR
- Multi-gate coordination, grouped dispatch, large-area coverage
SOL400Highway tunnel · Utility tunnel · Metro section
Tunnel / Utility Tunnel Coverage Package
- CONFIGURATION
- CV120 fiber BDA + CV310 ICS + S200 NMS
- BEST FOR
- 1–10 km long distance, zero dead zones, remote operations & maintenance
SOL500Residential · Commercial complex · Parking
Underground Garage Fill-in Package
- CONFIGURATION
- CV110 fiber BDA + Pro+ passives + S200 NMS
- BEST FOR
- Underground 1–3 floors fill-in; meets fire & emergency comms standards
SOL800Mine · Port · Power utility
SME Private Network Package
- CONFIGURATION
- Digital repeater + terminals + NMS + maintenance subscription
- BEST FOR
- No carrier dependency; independently built, self-controlled
SOL900Emergency command · Large events · Smart campus
Broadband–Narrowband Convergence Full-Stack Package
- CONFIGURATION
- KT-B broadband network + RS3100/RS3500 + S300 dispatch + S400 subscription
- BEST FOR
- Voice + video + positioning on one map; flagship broadband–narrowband convergence
06 / PRODUCT MATRIX
Six product families, one complete chain
Narrowband baseline + broadband value-add + unified dispatch NMS + maintenance subscription; models and certified versions per contract configuration
KINGTONE / JIMTOM
Every call,
answered.
From a single radio to a whole network: terminals, coverage, repeaters, bearers, and dispatch — all self-developed. KINGTONE delivers one thing only — comms online when it matters most.
- SRRC
- Radio model approval
- ISO
- 9001 / 27001 / 45001 triple system
- 13
- Utility-model patents
- 11
- Software copyrights
- 20+ yrs
- R&D accumulation
- 7000+
- Projects delivered
07 / QUALIFICATIONS & IP
Every capability has a verifiable number
Patent numbers, software-copyright registrations, system certifications — originals and registration info can be verified item by item during business engagement
13Utility-Model Patents
Four clusters: RF core, structural engineering, dual-/multi-band, fiber RF — patent numbers public and verifiable
11Software Copyrights
Covering NMS platform, device monitoring, and protocol conversion; earliest developed in 2007
4 typesSystems & Model Approval
High-Tech Enterprise · ISO 9001 / 45001 / 27001 triple system · SRRC model approval on multiple devices
A CLASS4 ITEMS
Dual-band / Multi-band
One RF front end adapts to multiple band combinations
- A dual-band BDAZL 2019 2 0571755.5
- An easily-installable dual-band BDAZL 2019 2 0571817.2
- A multi-band fiber BDAZL 2019 2 0544872.2
- An easily dis/assembled multi-band fiber BDAZL 2019 2 0571816.8
B CLASS5 ITEMS
Structural Engineering
Built for tunnel, underground, and coastal humidity & high-wind mounting
- A 350M fiber BDA with moisture-proof, heat-dissipating structureZL 2019 2 0544811.6
- A 400M fiber BDA with cable-management structureZL 2019 2 0544873.7
- A 350M fiber BDA with stable antenna mountingZL 2019 2 0544874.1
- A 400M fiber BDA with anti-detachment data interfaceZL 2019 2 0544875.6
- An easily-installable BDAZL 2019 2 0544815.4
C CLASS2 ITEMS
RF Core
Patent backing for passives and the low-noise receive chain
- A cross-band duplexerZL 2019 2 0544785.7
- A low-noise, heat-dissipating fiber RF BDAZL 2019 2 0571785.6
D CLASS2 ITEMS
Fiber RF
Fiber BDA whole-machine architecture and remote monitoring capability
- A fiber RF BDAZL 2019 2 0571799.8
- A communication BDA with remote working-state monitoringZL 2019 2 0572057.7
SOFTWARE COPYRIGHT (11 total; private-network-related registrations excerpted)Registration numbers verifiable
- BDA NMS Software V1.02024SR1851717
- All-Optical Network Coverage System Monitoring Software V1.02024SR1862186
- Kingtone GSM Digital Fiber BDA Monitoring Software V1.02010SR049131
- Kingtone WCDMA BDA Monitoring Software V1.02010SR049117
- Kingtone Optical Module Monitoring Software V1.02010SR049116
- Kingtone RS485 LNA Monitoring Software V1.02010SR049135
- Kingtone BDA Cooling System Control Software V1.02010SR049132
- Kingtone RS485 Frequency-Select Serial-Parallel Protocol Conversion Software V1.02010SR049130
- Kingtone RS485 Module Debugging Software V1.02010SR048606
Also available: information-security, quality-management and other system certification certificates, plus SRRC radio-transmission equipment model-approval certificates for multiple devices; upon request we can provide certificate copies and registration lookup paths during business engagement.
08 / DELIVERED RESULTS
20+ years of R&D, 7000+ projects delivered
All cases are delivered under our own brand and authorized; shown anonymized as “industry + scenario + scale”
A top-tier hospital5 buildings
RS3500 digital repeater + fiber BDA; medical / logistics / security three-network grouping, isolated channels in restricted zones
A highway tunnel3.2 km total length
CV120 fiber BDA + CV310 ICS same-frequency coverage; zero dead zones throughout, devices remotely managed
An urban complexUnderground 2 levels, 38,000 m²
CV110 + Pro+ passives + S200 NMS; seamless security patrol, stable comms during fire drills
A metal mineUnderground galleries + open-pit area
RS3500 + KT-B broadband network + S300 dispatch; radio / positioning / video on one map
A city emergency drill2 km² on-site
RS3100 portable same-frequency repeater + KT-B temporary network; command comms established within 30 min of public-network outage
A city marathon42 km along route
RS3100 + RS3000 high-power repeater + S300 dispatch; independent comms for security / medical / organizing committee
YOUR PROJECT
Want to see a full case close to your scenario?
Provide your project type and scale; we will produce a configuration list and timeline based on similar projects.
09 / TECH RESOURCES
Get private-network radio selection resources for free
A technical resource pack for integrators, design institutes, and owners — covering equipment selection logic, passive-component engineering red lines, and scenario configuration examples.
- Wireless Radio System Selection Manual
- Signal Extractor Application Guide
- Pro+ Passive NMS Access Whitepaper
- Hotel / Hospital / Campus Scenario Solutions
- Emergency Command & Dispatch System Solution
- Event Communications Support Solution
HOW IT WORKS
- 01Select materials
Tick the solution or manual you need on the downloads page
- 02Fill in info
Leave company and contact info for file delivery and project follow-up
- 03Get files
On verification, receive the download link immediately, valid for 30 minutes
We use your info only for resource delivery and project follow-up; the same resource need not be resubmitted within 24 hours.
10 / FAQ
The 8 questions integrators ask most before selecting
Structured FAQ for search-engine featured snippets and LLM citation; answers stay consistent with commercial commitments
01Why do hotel radios always cross-talk?
Traditional analog radios have few channels and high same-frequency reuse; when multiple departments share one channel they cross-talk. KINGTONE Solutions digital repeaters + grouping strategy let front desk, housekeeping, and security each talk independently.
02No signal for radios in the underground garage — what now?
Underground garages are dead zones. A fiber BDA or wireless broadband coverage solution pulls ground-level signal underground for full-area voice coverage. A typical project completes in 3–10 working days.
03What is the difference between same-frequency and split-frequency repeaters?
A same-frequency repeater transmits and receives on one frequency — simpler networking, direct-mode fallback, compatible with existing terminals. A split-frequency repeater uses different TX/RX frequencies and requires per-terminal frequency setup. RS3100 supports same-frequency relaying for faster deployment.
04Can the uplink and downlink signal extractors be swapped?
No. The uplink extractor (RF420) and downlink extractor (RF430) differ in frequency planning and port direction; swapping them breaks the system and a directional coupler cannot substitute for either.
05Can the broadband–narrowband dispatch system control terminals of any brand?
The S300 dispatch system is committed to dispatching KINGTONE Solutions’ own terminals and repeaters. For third-party terminals, the S200 NMS can bring them under monitoring; dispatch capability is evaluated case by case.
06How is underground mine communication covered?
We recommend a broadband–narrowband convergence architecture of “narrowband as baseline + broadband as value-add”: RS3500 digital repeaters guarantee underground voice, the KT-B LTE/5G private network carries personnel positioning and video backhaul, and the S300 dispatch console unifies command.
07How fast can a temporary network for a large event be deployed?
Using the RS3100 portable same-frequency repeater, devices go live on arrival — 1–3 days to complete temporary communications coverage for 1–10 km², recoverable the moment the event ends.
08Can you manage BDAs from other brands?
The KT-S200 NMS platform supports multi-brand device monitoring — a differentiating capability. Dispatch-class functions are evaluated case by case depending on device protocol support.
Still have questions? Call +86 595 28397999 or chat with us online.
11 / NEWS
Company News, Product Releases & Technical Articles
Syncs WeChat official-account content, curated into structured material citable by search engines and LLMs
12 / LET'S TALK
Can't find the right solution yet?
Leave your project info and our technical team will provide a customized solution and quote within 24 hours.
- Free on-site survey & assessment
- Customized system topology & configuration list
- Budget & implementation timeline advice
20+ years of R&D, 7000+ projects delivered — a standardized delivery process across 12 industry scenarios, ready to reuse.
